Introduction

FreePCB-2 is an open-source fork of the original FreePCB (v1.359), branched in 2014 and actively maintained to this day. Released under GPL-3.0 license for Microsoft Windows, the software is only about 50MB in size. It supports 1-16 copper layers with a maximum board size of 60x60 inches, with no pin or library limits. It includes a built-in schematic editor (Schematic Constructor), footprint wizard and footprint editor. The dynamic function key interface (F1-F9 changes based on selected object) combined with right-click context menu significantly improves routing efficiency. It supports cross-window copy/paste of PCB fragments, background image import for reverse routing, copper pour optimization, extended BOM export (PDF format, grouped by reference), and component datasheet/image/purchase link binding. Version 2.4.27 is planned for release in the first half of 2026.

Screenshots

Features

1-16 copper layer support
Up to 60x60 inch board size
No pin/library limits
Dynamic function key interface F1-F9
Built-in schematic editor
Footprint wizard & editor
Cross-window copy/paste PCB fragments
Background image import for routing
Copper pour optimization
Extended BOM export (PDF)
Component datasheet/image/link binding
Gerber RS274X / Excellon output
PADS-PCB netlist import/export
DXF / P-CAD ASCII format
Design rule check (DRC)
Auto-save (1.5 minutes)
Imperial/metric unit switching
